EasyStand Evolv XT Maximum Support Package
The EasyStand Evolv XT Maximum Support Package is a comprehensive solution designed to cater to the specific needs of larger individuals during standing activities. Tailored for those requiring extensive support, this package combines the versatility of the EasyStand Evolv standing frame with specialized accessories to ensure optimal stability, comfort, and safety.
Featuring adjustable supports for the trunk, pelvis, and knees, as well as additional positioning accessories, it offers customizable configurations to accommodate various levels of assistance and therapeutic requirements. With a focus on promoting independence and enhancing quality of life.
The Maximum support package includes: (no substitutions)
- PNG50499 – Easy-Adjust Seat Depth
- PNG50328 – Adjustable/Removable Actuator Handle
- PNG30000 – Large Contoured Chest Pad
- PNG30031 – Secure Foot Straps
- PNG50518 – Hip Supports
- PNG50384-1 Independent Kneepads
- PNG50174 – Removable Back
- PNG30306 – Velcro® Positioning Belt
- PNG50034 – Accessories Mounting Bracket
- Chest Strap or Chest Vest with High Mount Vest Bracket
- PNG50536 – Lateral Supports
- PNG50037 – Head Support
- PNG50517 – Shadow Tray
- PNG50015-1 Multi-Adjustable Foot Plates
- PNG30006-1 Planar Seat
- 5″ Front Wheels/Casters
- 5″ Rear Locking Casters
The minimum support package includes: (no substitutions)
Planar SeatSturdy support with Planar Seat for reliable comfort during activities.Multi-Adjustable Foot PlatesCustomize your comfort with Multi-Adjustable Foot Plates for optimal support.5in Front and 3in Back wheelsManeuver easily with 5-inch front and 3-inch back wheels.Easy-Adjust Seat DepthTailor comfort with Easy-Adjust Seat Depth for personalized support.Removable BackConveniently adjust support with Removable Back for enhanced comfort.Velcro® Positioning BeltSecure positioning with Velcro® Belt for reliable support and comfort.Large Contoured Chest PadMaximize comfort with Large Contoured Chest Pad for superior support.Manual Hydraulic Actuator with HandleEasily adjust with Manual Hydraulic Actuator for personalized positioning.Flip-Up Knee PadConvenient knee support with Flip-Up Knee Pad for adaptable comfort.Hip SupportSupports the hips in symmetrical alignment from sitting to standing.Accessories Mounting BracketRequired for attaching the chest vest, lateral supports, high mount chest vest bracket.Chest StrapFits users with chest measurements ranging from 46”-66” (116-167cm). Back required.Lateral SupportEnsure stability with Lateral Support for enhanced positioning and comfort.Head SupportEnhance comfort with Head Support for optimal positioning and relaxation.Swing-Away FrontEnhance accessibility with Swing-Away Front for easy maneuvering and transfers.
Order Forms
Evolv XT Itemized Order FormEvolv XT Package Order Form
Documents
Evolv XT Assembly Manual Evolv XT Instruction User Manual Evolv XT Catalog Evolv XT Mini Product Catalog
Specification
| Specification | Value |
|---|---|
| Approximate Height Range | 5’0″-6’2″ (152-188cm) |
| Weight Limit | 280lbs (127kg) |
| Maximum Mass (fully loaded unit) | 153lbs (69kg) |
| Seat Depth Range (from seat pivot) | 18”-23” (46-58cm) |
| Seat to Footplate Range (from seat pivot) | 14”-21” (36-53cm) |
| Knee Width (center to center) | 9” (23cm) |
| Kneepad Depth Range (from seat pivot) | 2”-7” (5-18cm) |
| Seat Height | 21.5” (55cm) |
| Seat Dimensions | 19″Wx21.5″L (48x54cm) |
| Standard Tray Size | 21”x24” (53x61cm) |
| Tray/Chest Pad Depth Range (from seat pivot) | 0”-10.5” (0-27cm) |
| Standard Tray Height Range (from seat pivot) | 15.5”-30.5” (39-77cm) |
| Footprint (at widest points) | 26.5”x33.5” (67x85cm) |
| Weight of Basic Unit | 104lbs (47kg) |
Limited Warranty
This warranty is extended only to the original purchaser/customer (or supplier non-consumer who does not buy or resell). Warrants EasyStand and Zing products against defects in materials and workmanship as listed below.
Steel Frames – 5-year warranty
Hydraulic Actuator – 2-year warranty
Gas Spring – 2-year warranty
Upholstered components, plastic pads, rubber parts, painted surfaces, bearings, and other parts not specifically identified above – 90-day warranty
